Name: Natural Circulation Superheater Reheater for Power Station Boilers
Brand: Zhangjiagang HuaDong Boiler Co., Ltd.
SKU: Überhitzer
Price: 3.00 USD
Availability: InStock

Mindestbestellmenge:	100 PCs
Preis:	2,000 - 5,000 USD per pc
Standardverpackung:	Seeangemessene Verpackung für den Export mit Eisen-Feld
Lieferfrist:	Innerhalb 90 Tage, nachdem die Anzahlung oder das L/C erhalten worden sind
Zahlungsmethode:	T/T, L/C am Anblick
Lieferkapazität:	Ungefähr 1.000 Tonnen pro Monat

Einzelheiten

Beschreibung des Produkts

Einzelheiten

Herkunftsort

China

Markenname

HD Boiler

Zertifizierung

ASME, ISO9001, EN

Modellnummer

Überhitzer

Typ:

Natürliche Zirkulation

Anwendung:

Wartung der Kessel, Kesselrohr, Heizungselement

Material:

Edelstahl

Verwendung:

Industriell, Kraftwerk, Wärmekraftwerk/Stationskessel

Farbe:

Individualisiert

Kraftstoff:

Biomasse, Abfälle

Inspektion:

ASME-Inspektion

Stil:

Horizontale und vertikale

Hervorheben:

natural circulation superheater

power station boiler reheater

superheater reheater with warranty

Beschreibung des Produkts

Horizontal-Type Superheater And Reheater Good Structural Rigidity Optimal

Product Specifications

Attribute	Value
Type	Natural Circulation
Application	boiler maintaince, Boiler Pipe, Heating element
Material	Stainless steel
Usage	Industrial, Power Station, Thermal power plant/station boiler
Color	Customized
Fuel	Biomass, Waste
Inspection	ASME Inspection
Style	Horizontal and Vertical

Key Differences Between Superheater and Reheater

Superheater handles saturated steam; reheater processes partially expanded steam.

Application

Use for heating saturated steam, steam temperature could be up to 900 degree C.

Superheater Capacity Upgrades to Increase Power Generation

Send us required technical data, such as steam capacity, pressure, required temperature etc. We will design accordingly.

Type Comparison

Type	Advantages	Disadvantages	Supporting method
Pendant-type	1. Firm structural support	1. Flow blockage by condensed steam 2. Needs a slow restart to purge the water that accumulates in the bottom.	supported from above
Inverted-type	1. Proper drainage of the condensed steam	1. Lack the structural rigidity, especially in high speed gas flow	Supported from below
Horizontal-type	1. Proper drainage 2. Good structural rigidity.	1. They do not view the flame directly so they are mainly from the convective type	Usually supported in the vertical gas ducts parallel to the main furnace.

Operating Principle

Principle of superheater is similar to steam generating tubes of boiler.
The hot gases at high temperature sweep over superheater tubes and raise the temperature of steam which magnitude depends upon exit gas temperature leaving the superheater and gas velocity.
